Logotipo Texsa, S.A.

MORTERPLAS SBS FV 2,4 KG GR-2

MORTERPLAS SBS FV is a non-self-protected membrane, made of SBS elastomeric bitumen, reinforced with fibre glass felt (FV), and finished with a thermally bonded or non-stick film with sand on both the upper and lower side.

Membrane with sand finishing on the upper and lower layer

Technical documentation

  • Logo Facebook
  • Logo Twitter
  • Logo Linkedin
  • Advantages
  • Application
  • Installation
  • Storage
  • Regulations
· Fibre glass felt (FV) reinforcement provides excellent dimensional stability to the product.
· The SBS elastomeric mastic provides the membrane with excellent flexibility at low temperatures, which allows it to be applied in cold climates.
· MORTERPLAS SBS FV 2.4 Kg GR-2 should always be installed in an adhered double-layer system, using hot oxyasphalt or ADHESIVO P or TEXSADH cold-applied adhesives to join the two layers.
· MORTERPLAS SBS FV 2.4 Kg GR-2 is used as a cold-applied auxiliary membrane in underground structures where installation is difficult: for use on foundations, slurry walls, walls; adhering to metal elements, starters for pillars, railings, over metal sheets, and on unique detailing where total adherence must be ensured.

Bottom layer in multi-layer systems for roofs, flooring and underground structures.
· SUPPORT: The surface must be dry, firm, even, clean and free of loose materials.
· It can be applied completely adhered, partially adhered or floating. · To adhere the membrane to the support, the support is primed with EMUFAL I. Once dry, use flame to adhere the membrane.
· For supports with a coarseness greater than or equal to 1.5, the adhesive system in the double-layer membrane involving the Adhesive P extension is cold application, as is the MORTERPLAS SBS FV 2.4kg GR2 bottom membrane, in systems that comply with DIT No. 579/11 MORTERPLAS VEHICULAR TRAFFIC.
· In areas where installation is difficult, the cold-applied MORTERPLAS SBS FV 2.4kg membrane is used with TEXSADH P1 mastic.

· The flame is applied as uniformly as possible (the greater the heat, the greater the retraction) along the width of the membrane without reaching the overlap, which will be done later, since it is important that the temperature be the same in every area. The flame should be applied until the anti-adherent film pore opens.
· The membranes are installed in such a way that no more than three membranes overlap at the same point.
· Overlaps are flame-bonded, with a minimum overlap of 8 cm.
· In the two-layer solution, the top membrane must be completely adhered to the bottom membrane, and it must be placed in the same direction so that the overlap lays approximately in the middle of the bottom membrane.
· Installation and measurements will be conducted in accordance with regulations of the UNE 104401 standard.
Roll: 1 m x 15 m
Pallet: 375 m²
· In accordance with the EN 13707 standard. Certified with CE marking No. 0099/CPD/A85/0087
· Voluntary certification of the product with AENOR seal according to the same European standard.
· With DIT No. 562/10 MORTERPLAS/MOPLAS ZERO slope
· With DIT No. 579/11 MORTERPLAS VEHICULAR TRAFFIC
· With DIT No. 580/11 UNDERGROUND STRUCTURES MORTERPLAS
· Quality System in accordance with ISO:9001
